Monoflanges

Process Monoflanges and Instrument Monoflanges are the most compact and cost-effective way for connecting process to pressure gauges or pressure transmitters.

Features

Standard Features
  • Bore Size
    5mm
  • ASME B 16.5 Flange Connections:
    – Flange Size 1/2″ to 3″ (DN 15 to DN80)
    – Flange Class 150 to 2,500
  • Outlet Connection
    1/2 NPT Female
  • Vent Collection
    1/4 NPT Female
  • Vent Valve with
    Anti-Tamper Head Unit incl. AT-Key
  • Monoflanges with Graphite Packing
    Fire Safe Tested and Certified acc. to
    ISO 10497 / API 607
  • Pressure Tested
    100% Pressure Tested EN 12266-1
    (MSS-SP61) and ASME B31.1
  • Sour Gas Service
    Supplied as Standard acc. to NACE
    MR0175/MR0103 and ISO 15156
  • Certification
    – Inspection Certificate acc. to EN 10 204
    – CRN and EAC Certificate available
Optional Features
  • Bore size
    10mm
  • Flange Connections
    – API up to 689 bar (10,000 psi)
    – EN 1092-1
  • Needle Seal
    With FKM O-Ring and
    Bellows Sealed Head Units
  • Needle Tip Materials
    Such as Stellite and Soft Tips
  • Swivel Gauge Connections
    Integral Type and Accessories
  • Pressure Tested
    Acc. to API 598
  • Fugitive Emission Application
    TA-Luft and ISO 15848 Solutions available
  • Oxygen Service
    Cleaned and Lubricated for Oxygen Service
